DemoElectrical engineering

Schematic, PCB and a fitting mechanical design by AI agents.

In two days, agents designed a sensor module with schematic and PCB, and an adapter plate between two flange standards.

Book a discovery callAll cases and demos
Render of the exploded assembly: ASME B16.5 Class 150 NPS 4 flange, gasket, 30 mm adapter plate, gasket, EN 1092-1 PN16 DN100 flange
Render from the STEP: adapter plate between an EN and an ASME flange
01 / The build loop

Designs that check themselves.

The build loop of the demo. Requirements go to the build agent, then to the checks and then to the reviewers. If an error or a blocking point is left, a new round starts at the build agent. Done when all is right. Requirementsfrom the question, with sources Builderschematic or model as code ChecksERC, DRC, netlist, dimensions Reviewersfour disciplines newround Done when all is right
Render of the top side of the 100 by 80 millimetre PCB with terminals, microcontroller and RS-485 isolation
PCB of 100 × 80 mm, from KiCad
errors in the schematic check (ERC)
0
errors in the PCB check (DRC)
0
netlist: all as expected
33/33
differences on 28 remeasured dimensions
0
02 / Your version

Your parts, your standards, your engineer in charge.

  • PartsIn the demo: Public librariesYour version: Your preferred parts and suppliers
  • StandardsIn the demo: Open tablesYour version: Your standards, as the source per dimension
  • ReviewIn the demo: Four AI reviewersYour version: Plus your engineer, with the last word
  • BrainIn the demo: Not in the demoYour version: In the ongoing partnership: one source over your projects, drawings and mail
Mail, documents, meetings and servers fly from all sides to one brain under a glass dome.
After the discovery call

A Startsprint of six working days on one real module or one real part. On day six you see what the loop builds and where your engineer steers.
